B71914-C-T-P4S-UL Machine tool main spindle bearing 70x100x16 mm, P4 Grade,B71914C.T.P4S.UL

Place of Origin : Germany

Brand Name : FAG

Model Number : B71914-C-T-P4S-UL

Certification : ORIGINAL

Price : NEGOTIATION

Packaging Details : Standard carton

Delivery Time : 2 days

Payment Terms : T/T

Supply Ability : 1000PCS/MONTH

MOQ : 2PCS

Contact Now

FAG bearings B71914-C-T-P4S-UL adjusted, in pairs or sets, contact angle α = 15°, restricted tolerances
d: 70mm D: 100mm B: 16mm
Type:	B	Standard Steel balls
Dimension series:	719	Light series
Dimension（dxDxh）		70x100x16mm
Contact angle:	C	C =15° E = 25°
Cages:	T	Plastic fiber cage, outer ring guided
Precision:	P4S	P4S FAG standard, reference to DIN620, higher than P4
Bearing arrangement:	U	single bearing, universal assemble
Preload:	L	light preload

B71914-C-T-P4S-UL High Precision Ball Bearing B71914.C.T.P4S.UL Machine tool main spindle bearing
B71914.C.T.P4S.UL FAG High Speed Angular Spindle Ball Bearing
15 degrees Contact Angle
P4 Grade
70mm x100mm x 16mm
Made in Germany

B71914.C.T.P4S.UL FAG High Speed Angular Spindle Bearing, Ball Bearing is Super precision Angular with 25 degrees contact angle and Phenolic cage, bearing is P4 quality and made in Germany

Item: B71914.C.T.P4S.UL FAG Ball Bearing，FAG machine tool main spindle bearing

Type: FAG Angular Spindle Ball Bearing

ball: steel

Quality: P4 Grade

Dimensions: 70mm x100mm x 16mm /Metric

ID (inner diameter)/Bore: 70mm

OD (outer diameter): 100mm

Width/Height/thickness: 16mm

Size:70 x 100 x 16 mm

Quantity: One Bearing

Dynamic load rating Cr: 33500 N

Static load rating Cor: 32500 N

Limiting Speed:

Grease Lubrication: 14000 RPM

Oil Lubrication: 20000 RPM

The delivery time: in stock, within one day after getting the order

Package:standard carton or standard wooden case

Shipping term:TNT,FEDEX,DHL Express or your required.
